FEMAC BD Heavy Duty Excavator Multi-Saw
The FEMAC BD Heavy Duty Multi-saw is designed for professional tree trimming and is suited to 3 – 10 tonne excavators.
High RPM saw blades cleanly cut up to 150 mm diameter vegetation. Perfect for roadside vegetation management contractors, fruit tree pruning and forestry applications.
This attachment is built with contractors in mind, designed to be low maintenance, durable and lightweight. The compact size allows it to be easily transported and stored.
Features:
- Tungsten tipped hard-wearing steel saw blades
- Individually replaceable 600mm diameter saw blades
- Blades spin at over 3000 RPM
- 150mm diameter cut
- Performance V-belt driven
- Deflector fins prevent material build up between saw blades during use
- Casappa cast iron hydraulic motor
- No case drain required
- Valve block complete with priority valve for adjusting oil flow, anti-shock valve (pressure relief valve), anti-cavitation.
- 107kg weight (without hitch)
- Protective blade covers for transport
- 3 models available – 2, 3 and 4 discs
- Includes hitch, hoses and couplings
| Model | Excavator (tonne) | Cutting width (cm) | Width (cm) | Weight (Kg) | Disc Diameter (cm) | No. of Discs | Engines |
RPM Max | Max Pressure (bar/PSI) | Oil L/min |
|---|---|---|---|---|---|---|---|---|---|---|
| BD2 | 3.0 – 10.0 | 10-15 | 122 | 73 | 60 | 2 | 1 | 3000 | 150 | 40-150 |
| BD3 | 3.0 – 10.0 | 10-15 | 156 | 107 | 60 | 3 | 1 | 3000 | 150 | 40-150 |
| BD4 | 3.0 – 10.0 | 10-15 | 204 | 144 | 60 | 4 | 1 | 3000 | 150 | 40-150 |
