FEMAC T9 REV Mulcher for 3-12 T Excavators
$ 11,750.00 – $ 26,400.00Price range: $11,750.00 through $26,400.00 ex GST
The FEMAC T9 REV is a high quality Italian mulcher attachment for excavators from 3T – 12T. With three sizes and three rotor options this mulcher can be configured to suit a range of machines for a variety of work. Great for land clearing, vegetation control, property maintenance, and forestry mulching.
REV stands for reversible. This mulcher is symmetrical in design, with identical input and output mouths, meaning it can be swept back and forth for continuous cutting without lifting off the ground. Unlike slasher style cutters, mulchers reduce vegetation into a finer material.
Available in swinging hammer flail mulcher and fixed tooth forestry mulcher configurations, in 700mm, 900mm and 1050mm cutting widths. Various tooth options are available for different vegetation types.
Rotor Options:
• MZ Helicoidal Rotor with swinging hammers
• FS Helical rotor with 360° rotating hammers
• DF Forestry rotor, fixed teeth
MZ Rotor with swinging hammers, Ideal for :
Small Trees
Fibrous Grasses
Lantana
Blackberry
Gorse
Hedges
Other Bushes and Scrub
Other Vegetation up to 80mm thick
FS Rotor with 360° rotating hammers, Ideal for:
Small-Medium Size Trees
Grass
Thick Overgrowth
Large Bushes
Dense Scrub
Work In Areas with Hidden Metal and Rock Debris
Other Vegetation up to 120mm thick
DF Rotor with fixed teeth, Ideal for:
Medium-Large Size Trees
Forestry Work
Hardwood
Thick Overgrowth
Large Bushes
Dense Scrub
Other Vegetation up to 250mm thick
Size Options:
T9-70 REV : 700mm cutting width
T9-90 REV : 900mm cutting width
T9-105 REV : 1050mm cutting width
Key Features:
Triple high-performance toothed V-belt transmission
Internally reinforced double-case body with interspace
Protective shield for belts and drive components
Symmetric shearing head, for a faster cut with the rotation of the excavator
Symmetrical Input and output mouths
Adjustable hoods, fully openable for higher cutting capacity
Side skids adjustable on 3 positions to change the height of the cut
Inside Rotor Supports with ”labyrinth” for the protection of the bearings from the impurities
Double Row spherical adjustable bearings of 1st quality
Valves block complete with priority valve for adjusting oil flow, anti-shock valve (pressure relief valve), anti-cavitation
Optional case drain
Casappa cast iron gear motor
Chain curtains for debris control
Made in Italy by FEMAC SRL
Model
Excavator (tonne)
Cutting width (mm)
Dimensions (WxDxH cm)
Weight (Kg)
Motor Displacement
Oil L/minPressure Bar (min-max)
Pressure
Transmission
Rotor
Flails
T9 MZ70 REV
3-6.0
700
85x80x60
180
16
30
170-220
3
Helical
10
T9 MZ90 REV
4.0-8.0
900
105x80x60
260
22-27-34
40-50-60
170-220
3
Helical
14
T9 MZ105 REV
6.0-10.0
1050
125x80x60
310
22-27-34-44-51
40-50-60 80-100
200-220
3
Helical
16
T9 FS70 REV
5.0-8.0
700
85x80x60
290
22-27-34-44-51
40-50-60 80-100
200-220
3
Helical
12
T9 FS90 REV
6.0-8.0
900
105x80x60
360
22-27-34-44-51
40-50-60 80-90
200-220
3
Helical
18
T9 FS105 REV
6.0-12.0
1050
125x80x60
400
27-34-44-51
50-60 80-90
200-220
3
Helical
22
T9 DF70 REV
5.0-12.0
700
85x80x60
340
22-27-34-44-51
40-50-60 80-100
200-220
3
Helical
21
T9 DF90 REV
6.0-12.0
900
105x80x60
400
27-34-44-51
50-60 80-100
200-220
3
Helical
24
T9 DF105 REV
6.0-12.0
1050
125x80x60
460
27-34-44-51
50-60 80-100
200-220
3
Helical
30
Rotor Options :
MZ – Swinging Hammers Rotor
FS – 360° Rotating Hammers Rotor
DF – Fixed Tooth Forestry Rotor
Teeth Options:
HF3 – max Ø 8 cm – standard (MZ Rotor only – Standard)
KF3 – max Ø 6 cm (MZ Rotor only – Optional)
HF17 – max Ø 12 cm (FS Rotor)
HF14 – max Ø 25 cm (DF Rotor Only – Standard )
HF15 – max Ø 20 cm (DF Rotor Only – Optional )
Other Accessories:
Feeler Roller (+50kg)
Self Levelling Support (+40kg)
Variable Displacement Piston Motor (manually adjustable)
