OMEF CS Excavator Forestry Pruner
The OMEF CS Excavator Forestry Pruner is a versatile attachment designed for excavators ranging from 1.6 to 24 tonnes. Perfect for pruning and chopping both small and large trees, it offers exceptional cutting power.
Crafted with a blade made from specialised XAR500 anti-wear steel, the pruner guarantees superior cutting performance, even in demanding conditions. The high force produced by the hydraulic cylinder, coupled with its 360° rotation system, ensures maximum flexibility and excellent grip during operation, making it easy to manoeuvre through various tasks.
The standard version, available in four sizes, has been enhanced with the new “H” series. This advanced version is specifically designed to tackle particularly tough and fibrous woods, offering enhanced durability and cutting efficiency.
Perfect for forestry, landscaping, and maintenance operations, this attachment is built to withstand heavy-duty use while delivering outstanding performance.
Manufactured in Italy.
| CS100 | CS200 | CS300 | CS400 | CS400H | |
| Excavator class weight | 1.6 – 3.5 T | 3.5 – 6 T | 6 – 10 T | 10 – 24 T | 10 – 24 T |
| Attachment weight | 120 Kg | 210 Kg | 340 Kg | 550 Kg | 570 Kg |
| Dry cut diameter | 80 mm | 180 mm | 300 mm | 390 mm | 390 mm |
| Green cut diameter | 110 mm | 210 mm | 320 mm | 410 mm | 420 mm |
| Oil pressure | 180 – 250 bar (min-max) | 180 – 250 bar (min-max) | 180 – 250 bar (min-max) | 200 – 300 bar (min-max) | 200 – 300 bar (min-max) |
| Hydraulic flow | 20 – 45 l/min (min-max) | 20 – 60 l/min (min-max) | 20 – 60 l/min (min-max) | 30 – 80 l/min (min-max) | 30 – 80 l/min (min-max) |
| Spin | 360° | 360° | 360° | 360° | 360° |
